No need for accessibility due to resettable protection.
Wire harness optimization in terms of cost and weight by protection adjustable to system requirements.Accurate protection of the wires by hardware, independent from microcontroller sampling and control.Wire protection: PROFET™ Load Guard protects and diagnoses the wires in the power distribution system.PROFET™ Load Guard offers state-of-the-art diagnostic and protection features.Adjustable overcurrent limitation enables configuring the device according to the system needs.Capacitive load switching mode allows the device to safely switch big capacitors without the need of oversizing the switch or additional pre-charge circuitry.Load control and self-protection: PROFET™ Load Guard protects itself and controls the load connected to the device output with PROFET™ basic feature set and capacitive load switching mode.Simplified power over coax (PoC) implementation.adjustable overcurrent thresholds according to the load current requirements.protection of sensitive loads, such as ECUs, avoiding high peak currents.Load supply protection: PROFET™ Load Guard protects the supply infrastructure connected to the switch output with adjustable overcurrent limitation.With the standard PROFET™ feature set plus the advanced features adjustable overcurrent limitation and capacitive load switching mode, the PROFET™ Load Guard can address new use cases of upcoming power distribution networks: Load supply protection, load control and self-protection, wire protection and power supply protection.
Smarts load driver#
Especially autonomous driving and advanced driver assistance systems benefit from the adjustable current limitation by protecting sensitive input and output filters of sensors.
Smarts load iso#
Furthermore, the family offers to perform precise module diagnosis with best in class current sense accuracy in smart switches in low current regions (kILIS) and ISO 26262-ready documentation supports the use in safety-related applications.Īll in all, the PROFET™ Load Guard is a flexible device to fulfill the needs of upcoming automotive power distribution generations. With the integrated capacitive load switching mode, a broad range of capacitive loads can be charged in the safe operating area.
Exchanging devices within the PROFET™ Load Guard family is simple, as the single and dual-channel devices in the established PG-TSDSO-14 exposed pad package are pin and function compatible. This minimizes design-in efforts by setting up only one design, as the current limit can be adapted on demand if load-driving requirements change. The PROFET™ Load Guard portfolio is characterized by the highest design flexibility, provided by the possibility to adjust the overcurrent limitation of each device, according to the load requirements.
